Checklist for Indoor Air Quality Ventilation Systems

Why a Structured Checklist Matters

Building owners and engineers need a repeatable method to verify indoor air quality performance. A structured checklist turns subjective impressions into measurable data points. It forces auditors to check the same critical components every visit.

This format works well for commercial air handling units, rooftop units, and dedicated outdoor air units. It also applies to smaller air flow systems in offices, labs, and healthcare facilities. The goal is not just to find problems. The goal is to build a record that supports maintenance, compliance, and future upgrades.

A good audit separates observation from inference. If a sensor reads high CO2, the auditor records the number and the timestamp. The auditor does not guess why. The next step is to check the ventilation requirements and the air flow systems that respond to that sensor.

Section 1: Verify Ventilation Requirements

Start with the design intent. Pull the original specifications, as-built drawings, and commissioning reports. If these documents are missing, reconstruct the intended air flow from the equipment nameplates and duct sizing.

Compare the required outdoor air volume against the measured supply air volume. Check the local ventilation requirements that apply to the building type. These rules define the minimum air flow per occupant and per floor area. They also set minimum outdoor air fractions for specific spaces.

Red flags:

• The design documents list a specific air flow rate, but the nameplate does not match.
• The measured air flow is below the design value by a significant margin.
• The outdoor air damper is stuck partially closed during occupancy.
• The space uses a higher occupancy density than the design assumed.

If the measured air flow is consistently low, the system may not meet ventilation requirements. This is a compliance issue. It also affects indoor air quality because insufficient dilution of CO2 and volatile organic compounds will occur.

Section 2: Inspect Air Flow Systems

Air flow systems include the fan, ductwork, diffusers, grilles, and dampers. A leaky or blocked system cannot deliver the required air flow.

Walk the ductwork. Look for gaps at joints, splits, and connections. Use a visual check for dust buildup and condensation. If you have access, use a smoke pencil or thermal imaging to detect leaks. Leaks in return ducts can draw unconditioned air or contaminated air from ceilings or floors.

Check the fan. Verify the belt tension, if belt-driven. Listen for unusual bearing noise. Confirm the fan speed matches the design setting. A fan running at 50 percent speed will deliver roughly 50 percent of the designed air flow, though pressure losses can change the actual result.

Red flags:

• Visible dust accumulation on the fan housing and inside the plenum.
• Duct joints with missing gaskets or loose clamps.
• Diffusers with visible obstruction from furniture or drapery.
• Damper actuators that are not responding to command signals.

Section 3: Check Filtration Performance

Filtration protects occupants and equipment. It also affects air flow resistance. A clogged filter increases static pressure and can reduce air flow.

Inspect the filter media. Look for tears, bypass channels, and visible dust loading. Check the filter frame for corrosion and damage. Verify the filters are the correct rating and size. A common mistake is installing a lower rating filter to reduce pressure drop. This passes more particles but fails to meet indoor air quality standards for particulate matter.

Measure the static pressure across the filter bank. Compare it to the baseline recorded during installation or the last clean. A significant increase indicates loading or a restriction.

Red flags:

• Filters with visible gaps or bypass air around the edges.
• Media that is discolored or has visible mold growth.
• Static pressure across the filter is higher than the baseline by a measurable amount.
• The system bypasses the filter bank entirely due to a stuck damper.

Section 4: Assess Air Quality Sensors and Controls

Sensors drive the controls. If the sensors are dirty or miscalibrated, the controls will make wrong decisions.

Check the CO2 sensors. Verify the location is representative of the occupied zone. Avoid placing them near doors or exhaust fans where air mixing is poor. Confirm the sensor reads a stable baseline when the space is unoccupied.

Check the humidity sensors. High humidity promotes microbial growth and odors. Low humidity causes static and discomfort. Verify the sensor is not exposed to direct condensation or steam.

Review the control logic. Does the system modulate the outdoor air damper based on CO2? Does it ramp up when occupancy increases? Does it shut down or reduce air flow during unoccupied hours?

Red flags:

• CO2 sensor reads a constant value regardless of occupancy.
• Humidity sensor reads below 30 percent or above 60 percent consistently.
• Controls are in manual mode instead of automatic.
• Sensor data does not match the trend of the supply air temperature and flow.

Section 5: Review Ductwork and Distribution

Ductwork distributes the air. Poor distribution creates hot and cold spots. It also causes uneven CO2 levels.

Check the diffusers. Are they clean? Are they directing air in the intended pattern? A diffuser that is aimed at a wall or a ceiling tile can cause discomfort and poor mixing.

Check the return air grilles. Are they blocked by carpets, furniture, or storage? Blocked returns increase static pressure and reduce overall air flow.

In a larger building, check the zone dampers. Verify they are opening and closing correctly. If a zone damper is stuck open, air bypasses the intended space. If it is stuck closed, that space receives no fresh air.

Red flags:

• Diffusers with visible damage or misalignment.
• Return grilles with visible dust or obstruction.
• Zone dampers that do not change position when commanded.
• Air flow at terminal diffusers is significantly lower than design.

Section 6: Document and Report

A checklist without documentation is just a walk-around. Record every finding. Use the format below to keep the report consistent.

Component	Design Value	Measured Value	Status	Action Required
Supply Air Flow	12,000 CFM	10,500 CFM	Low	Check fan speed and duct leaks
CO2 Sensor	400 ppm baseline	850 ppm baseline	Faulty	Calibrate or replace sensor
Filter Static Pressure	0.15 in. w.c.	0.22 in. w.c.	High	Replace filters
Outdoor Air Damper	100% open at peak	60% open at peak	Stuck	Repair actuator and linkage
Diffuser Air Flow	2,000 CFM	1,800 CFM	Acceptable	Monitor next audit

The status column should use simple terms: OK, Low, High, Faulty, or Stuck. The action required column must be specific. Do not write “check the system.” Write “replace filter media at bank two.”

After the audit, assign a priority to each action. Critical items affect immediate health or compliance. Major items affect comfort and long-term equipment life. Minor items can be scheduled for routine maintenance.

Section 7: Frequency of Audit

How often should you run this checklist? It depends on the building type and the risk.

For office spaces, a full audit once a year is standard. For healthcare, labs, and food service, a semi-annual or quarterly audit may be required by local rules or best practice.

After any major repair, change of occupancy, or seasonal transition, run a partial audit. Check the air flow, outdoor air damper, and CO2 sensor. These are the most common failure points.

Keep the audit records for at least three to five years. This supports compliance reviews and helps identify trends. If the same component fails every audit, the issue is design or material, not just wear.

Common Mistakes in IAQ Audits

• Checking only the supply air flow and ignoring the return air flow.
• Measuring air flow at the wrong point in the duct system.
• Ignoring the outdoor air damper position.
• Assuming the CO2 sensor is accurate without a baseline check.
• Focusing on comfort complaints without checking the ventilation requirements.
• Failing to document the findings in a way that supports corrective action.

A checklist is only as good as the person using it. Train the auditor on the specific equipment. Make sure they know where the sensors are, how the controls work, and what the design values are.

Indoor air quality is a system problem. It is not one filter or one fan. It is the interaction of ventilation requirements, air flow systems, filtration, and controls. An audit checklist forces you to look at all of them. That is what separates a real performance check from a casual walk-around.
